Frame
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing
Size
Size Split: 27.5: S // 29: M L XL
Suspension Fork
Fox 36 Float AWL, RAIL Damper, Tapered, 15x110mm, E-Bike Optimized, 150mm
Shock
Fox Float Rhythm R, 230x60mm (27.5: 210x55mm), Rebound Adjust
Shock Hardware
Front: 30x8mm, Rear: DU-Bushing 12,7mm
Drive Unit
Bosch Drive Unit Performance Line CX, Smart System
Remote
Bosch System Control incl. Mini Remote
Battery
Bosch PowerTube
Display
Bosch Display
Charger
Bosch 2A
Brake System
Magura MT Thirty, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203)
Rear Derailleur
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed
Shifters
Shimano Deore SL-M6100, Rapidfire-Plus
Crankset
ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T
Cassette
Shimano Deore CS-M6100, 10-51T
Chain
KMC e12
Chain Guide
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
Headset
ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment
Stem
CUBE Performance Stem E-MTB 35, FPI-Link
Handlebar
CUBE Rise Trail Bar 35
Grips
ACID Disrupt
Rims
CUBE EX30, 32H, Disc, Tubeless Ready
Front Hub
CUBE Engineered By Newmen, 15mm, Boost, 6-Bolt
Rear Hub
CUBE Engineered By Newmen, 12mm, Boost, 6-Bolt
Front Tyre
Schwalbe Hans Dampf, Addix Soft, Super Trail, Tubeless Easy, 2.6
Rear Tyre
Schwalbe Hans Dampf, Addix Speedgrip, Super Trail, Tubeless Easy, 2.6
Saddle
ACID Venec EMTB Trail 140
Seat Post
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
Colour
blackline
Weight
24,4 kg
