Frame | C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing |
Fork | SR Suntour Aion 38X 2CR Air, Tapered, 15x110mm, Lockout, 170mm |
Rear Shock | SR Suntour Edge EVO 2CR 230x65mm |
Headset | Acros AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment |
Stem | CUBE Performance Stem E-MTB 35, FPI-Link |
Bars | CUBE Rise Trail Bar 35 |
Front Brake | Magura MT Thirty, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203) |
Rear Brake | Magura MT Thirty, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203/203) |
Rear Mech | Shimano Deore RD-M6100-SGS, ShadowPlus, 12-Speed |
Shifters | Shimano Deore SL-M6100, Rapidfire-Plus |
Speed | 12 |
Rims | CUBE EX30, 32H, Disc, Tubeless Ready |
Front Hub | CUBE Engineered By Newmen, 15mm, Boost, 6-Bolt |
Rear Hub | CUBE Engineered By Newmen, 12mm, Boost, 6-Bolt |
Front Tyre | Schwalbe Magic Mary, Performance, 2.4 |
Rear Tyre | Schwalbe Big Betty, Performance, 2.4 |
Seat Post | CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm |
Saddle | ACID Venec Lite |
Chainset | ACID MTB Hybrid Pro, 36T |
Chain | KMC e12 |
Cassette | Shimano Deore CS-M6100, 10-51T |
Battery Size (WH) | Bosch PowerTube 800 |
Motor | Bosch Drive Unit Performance Line CX, Smart System |
