Motor -SyncDrive Sport, 75Nm
Controller -RideControl Dash
Display -RideControl Dash, full Colour lcd screen
Battery -EnergyPak Smart 625, EnergyPak Plus 250Wh range extender compatible
Connectivity -Giant RideControl App enabled ANT+ wireless display signal with E-bike profile
Sizes -S, M, L, XL
Colours -Cold Iron
Frame -ALUXX SL-grade aluminium, 125mm travel FlexPoint suspension system, 148x12 rear axle, Universal Derrailleur hanger, 184x44 shock, 1.5~1.8" headset
Fork -RockShox 35 Silver, 140mm, tapered steerer, 110x15 thru-axle
Shock -SR Suntour Raidon R, 190x45mm, custom tuned
Handlebar -Giant Connect TR Riser 31.8x780mm
Grips -Giant Tactal single lock-on
Stem -Giant Contact
Seatpost -Giant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170)
Saddle -Giant Sport
Pedals -Flatpedal
Shifters -Shimano Deore LinkGlide
Front Derailleur -MRP HD2 co-moulded chain guide
Rear Derailleur -Shimano Deore LinkGlide, 10-speed
Brakes -Shimano BR-M420, 4-piston, hydraulic disc, 203mm
Brake Levers -Shimano Deore
Cassette -Shimano LinkGlide, CS-LG400-10, 11-43T, 10-speed
Chain -Shimano, LinkGlide, CN-LG500
Crankset -FSA Comet E-Bike crank arm setFSA MegaTooth Direct-mount 1X steel 36T
Bottom Bracket -n/a
Rims -Giant AM 29", Tubeless ready, 30mm inner width
Hubs -Giant eTracker Boost, [F] 110x15 [R] 148x12mm
Spokes -Stainless Steel
Tyres -Maxxis Minion DHF 29X2.50" Foldable, TLR, EXO, 60TPI [F]Maxxis Dissector 29X2.40" WT Foldable, TLR, EXO, 60TPI [R]
Lock-Torx 25 Battery Lock with built-in Torque limiter
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
