Sizes27.5: XS,S 29: M,L,XL,XXL
ColoursGloss Radiant Orange, Satin Black
Frame ALUXX-grade aluminium, disc
Fork SR Suntour XCE, QR, steel steerer XS&S: 80mm travel (27.5) M-XXL:100mm travel (29)
Shock N/A
Handlebar Giant Connect Trail, 31.8mm XS&S: 690mm (27.5) M-XXL: 780mm (29)
GripsGiant Sole-O
Stem Giant Sport, 7-degree rise
Seatpost Giant Sport, 30.9mm
SaddleGiant ErgoContact Trail
Pedals MTB caged
Shifters microSHIFT Acolyte, 1x8
Front Derailleur N/A
Rear Derailleur microSHIFT Acolyte
Brakes Tektro 172, mechanical, Tektro rotors [F]160mm, [R]160mm
Brake Levers Tektro TBK 172, mechanical
Cassette microSHIFT, 12x46
Chain KMC 8.3
Crankset ProWheel Forged, 33t (27.5) or 30t (29)
Bottom Bracket cartridge
Rims Giant GX03V 29 or 27.5, alloy, double wall, 21mm inner width
Hubsalloy, sealed bearing, [F] 15x110 thru axle, [R] 12x142 thru-axle
Spokes stainless, 14g
Tyres Maxxis Ikon 27.5x2.2 or Maxxis Ikon 29x2.2, wire bead
Extras -
Max Tyre Clearance 2.4"
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
